GPS01 Module - Low Cost Very High Performance
DataSheet
The GPS01 is a small form factor GPS module solution intended for a broad range of Original Equipment Manufacturer (OEM) products, where fast and easy system integration and minimal development risk is required.
The GPS01 GPS receiver’s -157dBm tracking sensitivity allows continuous position coverage in nearly all application environments. Its high performance search engine is capable of testing 8,000,000 time-frequency hypotheses per second, offering industry-leading signal acquisition and TTFF speed.
The receiver is optimized for applications requiring high performance, low power, and low cost; suitable for a wide range of OEM configurations including mobile phone, PND, asset tracking, and vehicle navigation products.
The very small 13mm x 16mm form factor and the SMT pads allow standard surface mount device pick-and-place process in fully automated assembly process; enabling high-volume, very cost-efficient production.
- 65 channel engine for high performance acquisition
- GPS L1 C/A Code
- Perform 8 million time-frequency hypothesis testing per second
- Open sky hot start 3 sec
- Open sky cold start 36 sec
- Signal detection better than –157dBm
- Reacquisition sensitivity –143dBm
- Accuracy 5m CEP
- Tracking current < 50mA
- Support active antenna
- SBAS (WAAS, EGNOS) support
- Small size 15.9 x 13.0 x 2.7 mm (LxWxH)
